System Power: 12 V truck power required, current drain less than 20 mA (not including alarm outputs)
Accuracy: Ground resistance measurement accuracy is ±2% at the switching point (10 ohms or 250 ohms). Accuracy is ±5% at measurement extremes.
Ambient temperature range: -40°F to +140°F (-40°C to +60°C) ambient
Alarm output ratings: Both alarm outputs can provide at least 2 amps to the load. Maximum voltage is 16 V. Outputs are internally protected from short circuits and voltage spikes.
Maximum tank height: 1 amp at 15 Vdc
Material: Cast aluminum enclosure
Size: 226 mm (8 7/8”) wide, 143 mm (5 5/8”) high, 92 mm (3 5/8”) deep
